Aqara Roller Shade Controller T1S

Description

Aqara Roller Shade Controller T1S — Whisper-Quiet Automated Roller Blinds

Turn your roller blinds into smart blinds. The Aqara Roller Shade Controller T1S slips inside a standard 38 mm roller tube and motorises it with a slim 25 mm DC motor that runs at under 27 dB — quiet enough to open your bedroom blinds without waking anyone. It works with zebra (Korean) blinds, Shangri-La blinds and honeycomb blinds as well as classic roller shades, making it a natural fit for HDB, BTO and condo windows across Singapore.

Wake up with the sun, not an alarm. Set schedules so your shades open and close at exact times, or use Quiet Mode to let them glide open gradually over a preset period — a gentle, natural way to start the morning. Pair with Aqara sensors for automations like closing the blinds when the afternoon sun heats the room, cutting aircon load and protecting your furniture.

Control it your way. Operate from the Aqara Home app, by voice, or through your existing smart home platform. With an Aqara Matter-compatible hub, the T1S is exposed via Matter to Apple Home (including Siri), Google Home, Amazon Alexa, Samsung SmartThings and Home Assistant.

Key Features

• Ultra-quiet operation: advanced DC motor rated under 27 dB, with Quiet Mode for slow, silent movement.
• Scheduled operation: open and close your shades automatically at set times, every day.
• Smart automations: trigger shades from Aqara sensors, scenes and other smart home events.
• Remote and voice control: Aqara Home app anywhere, plus Siri, Alexa and Google Assistant via your hub.
• Matter support: works with Matter over an Aqara bridge for broad platform compatibility.
• Wide shade compatibility: roller shades, zebra roller blinds, Shangri-La blinds and honeycomb blinds on 38 mm tubes.

Product Specifications

• Model: CD-M03D
• Rated voltage: 100–240V AC, 50/60Hz (24V DC motor control box included)
• Rated power: 20 W
• Rated current: 0.3 A
• Rated torque: 1.2 N·m
• Rated rotor speed: 25 r/min
• Noise level: under 27 dB
• Fits roller tube diameter: 38 mm (motor body Ø25 × 465 mm)
• Wireless: Zigbee (Matter over Aqara bridge), Bluetooth 5.0, NFC
• Protection rating: IP40
• Operating temperature: −20℃ to +55℃
• Operating humidity: 10%–95% RH, non-condensing

Which Aqara roller shade motor do I need?

• Roller Shade Controller T1S (this product): mains-powered in-tube motor for 38 mm tubes — the choice for new or re-tubed roller blinds that should look completely built-in.
• Roller Shade Driver E1: battery-powered retrofit unit that turns the bead chain of your existing blinds — no re-tubing needed.
• Roller Shade Controller TA: heavy-duty 8 N·m tubular motor for 35 mm tubes — the choice for large, heavy or extra-wide roller shades.

Requires an Aqara Zigbee 3.0 hub (or compatible third-party Zigbee 3.0 gateway) for app, voice and Matter functionality.

Note: Motor only — roller tube, fabric and brackets are part of your blind hardware.
