Aqara Display Switch V1

Description

The Aqara Display Switch V1 (model WS-K02D) is a two-gang, with-neutral Zigbee wall switch with a 2.08-inch LCD strip and four flat buttons: the two on the left switch the wired circuits, the two on the right are wireless scene buttons, and the screen labels each of them in your own words. It also measures the power the wired loads draw, wakes its display when someone walks within 2.5 m, and acts as a Zigbee repeater for the rest of the room. Sold by PassionHome — your Authorised Aqara Dealer in Singapore — at S$199 with the official 24-month Aqara warranty.

Why buy the Aqara Display Switch V1 in Singapore

• Labels you can read. The LCD shows a custom name and icon for every button — Living, Cove, Good night, Curtain — with adjustable text size and colour, so nobody presses the wrong switch again.
• Two wired plus two wireless. It replaces a 2-gang switch and adds two spare scene buttons in the same 86 mm plate; the two wired channels can also be turned into wireless buttons if the lights themselves are smart.
• Power monitoring built in. See what the connected lights or fan draw, charted by day, week and year, and use it in energy-saving automations.
• Proximity activation. A built-in presence sensor lights the screen as you approach (within 2.5 m, sensitivity adjustable) and can trigger automations — a dim night light as you walk up, for example.
• Matter over Bridge and seven ecosystems. Through an Aqara Hub M3 it reaches Apple Home, Google Home, Amazon Alexa, SmartThings, Homey and Home Assistant, as listed by Aqara.
• Authorised dealer stock. Official 24-month Aqara manufacturer warranty, serviced in Singapore through the Aqara Service Center. Estate group-buy pricing is available when your estate unlocks it.

A screen that tells you what each button does

Most smart switches end up with a strip of masking tape on them. The Display Switch V1 solves that with a 2.08-inch LCD across the middle of the plate: each of the four buttons gets a label, an icon and a colour set in Aqara Home, and the screen doubles as a clock when idle. The two left buttons are the wired channels (L1 and L2) — typically the room’s main lights — and the two right buttons are wireless, free to run any scene or device on your hub, from the curtain driver to a Leaving home scene.

If the lights on a wired channel are themselves smart — Aqara ceiling lights or bulbs, say — the channel can be converted to wireless control so the switch never cuts power to them. That is the role of Aqara’s MARS technology (Multi-load-type Adaptable and Reliable Switching): it keeps smart lights online and their on/off state in sync across the switch and the apps, whatever load type is connected.

Power monitoring and proximity activation

The switch measures the energy consumption of the devices on its wired channels and charts it by day, week or year in Aqara Home. For a Singapore household that is most useful on the circuits that run longest — a living-room fan and lights, a study — and the readings can drive automations such as a reminder when a light has been on all night.

A built-in presence sensor wakes the display when someone comes within about 2.5 m, with adjustable sensitivity and distance, so the screen is dark at night until you approach. The same detection is exposed as an automation trigger — IF someone approaches THEN set the corridor light to 10% is the example Aqara gives.

Hub, Matter and ecosystems

The Display Switch V1 is a Zigbee 3.0 device with Bluetooth for setup — it has no Wi-Fi and it needs an Aqara Zigbee hub to work at all. For Aqara Home and Apple Home, any current Aqara hub does; for the wider list Aqara publishes — Google Home, Amazon Alexa, Samsung SmartThings, Homey and Home Assistant — the switch is exposed through Matter over Bridge, which needs a Matter-bridge hub such as the Hub M3 or Hub M200. Once on the hub it also works as a Zigbee repeater, which helps battery sensors in the same room.

Installing the Display Switch V1 in a Singapore home

Neutral wire required

This is a two-channel with-neutral switch: L, N, L1 and L2 terminals, 200–240 V AC, up to 8 A resistive. Most Singapore switch boxes carry only the live wire, so it is best specified during a renovation or reinstatement when an electrician can bring a neutral to the box — our neutral vs no-neutral guide explains what to ask for. Where a neutral is not possible, the Light Switch H2 is the no-neutral alternative.

Box depth and installation

The plate is the standard 86 × 86 mm and the body is 42.2 mm deep, so check the wall box before ordering. It is an electrical switch for indoor use only (−10°C to 40°C), must be installed by a licensed electrician, and Aqara specifies a maximum screw torque of 0.7 N·m on the terminals. If you would like PassionHome to check your switch layout first, message us on WhatsApp at +65 9051 7063.

Display Switch V1, Touchscreen Dial V1 or Panel Switch S100?

All three are with-neutral 86 mm panels. The Display Switch V1 is the two-gang switch with a labelled LCD and Zigbee (hub required). The Touchscreen Dial V1 is a Wi-Fi rotary dial with a round screen and no hub role, built for dimming. The Panel Switch S100 is a three-gang full touchscreen that is itself a Zigbee hub. Pick the Display Switch where clarity and a modest price matter; the S100 where you want one panel to run the whole flat.

Specifications (WS-K02D)

Specification	Detail
Model	WS-K02D
Type	Two-gang with-neutral wall switch; 4 buttons (2 wired + 2 wireless) with 2.08-inch LCD
Wireless	Zigbee 3.0 + Bluetooth; Aqara Zigbee hub required; acts as Zigbee repeater
Matter	Matter over Bridge via a Matter-bridge Aqara hub (e.g. Hub M3)
Ecosystems (per Aqara)	Aqara Home, Apple Home, Amazon Alexa, Google Home, Samsung SmartThings, Homey, Home Assistant
Rated parameters	200–240 V AC, 50/60 Hz, max 8 A resistive; terminals L, N, L1, L2
Wiring	Neutral wire required
Sensors	Built-in presence sensor for proximity activation (about 2.5 m, adjustable)
Power monitoring	Yes — wired channels; day / week / year charts
Dimensions	86 × 86 × 42.2 mm; 205 g
Operating temperature	−10°C to 40°C
Operating humidity	0–95% RH, non-condensing
Use	Indoor only; professional installation required

What is in the box

Display Switch V1 ×1, screw kit ×2, user manual ×1, compliance statement ×1.

Warranty and authorised-dealer details

PassionHome.sg is an Authorised Aqara Dealer in Singapore, listed on Aqara’s official partner network. All Aqara products sold here:

• Carry the official 24-month Aqara manufacturer warranty
• Are sourced direct from Aqara distribution channels — never grey-market
• Are covered by Singapore-based warranty service through the Aqara Service Center — no overseas RMA

Warranty term is 24 months from the purchase date. For a warranty claim on your Display Switch V1, the unit goes to the Aqara Service Center, Singapore’s official Aqara warranty service location. PassionHome can guide you through the process if you run into any issues — reach out on WhatsApp at +65 9051 7063.
